AquaStar | PLP150S | Pipeline Smart Model Variable Speed Pump, 1.5 HP, 230 V
Couldn't load pickup availability
Got questions?
Feel free to get in touch
The AquaStar PLP150S Pipeline Smart Model is a 1.5 HP variable speed pump designed for superior efficiency, quiet operation, and versatile performance. Running on 230V single-phase power, it offers a broad speed range and programmable controls, making it ideal for modern residential pool and spa applications.
Key Features
-
1.5 HP variable speed motor with RPM range from 800–3,400
-
Permanent Magnet Motor (PMM) for maximum energy efficiency
-
Totally Enclosed Fan Cooled (TEFC) design for motor protection and durability
-
Four programmable speed settings for customizable operation
-
Noise-reducing vibration dampening for quiet performance
-
2" and 2.5" union connections for flexible plumbing compatibility
-
Large-capacity strainer basket with easy-release, quarter-turn locking lid
-
Weighted Energy Factor (WEF) of approximately 7.2 kgal/kWh for high efficiency
-
RS-485 communication ready for integration with major pool automation systems
-
Rugged, weather-resistant construction for long service life
Product Overview
The AquaStar PLP150S Pipeline Smart Variable Speed Pump combines modern technology with energy-saving performance, delivering exceptional circulation for pools and spas. Its permanent magnet motor and programmable controls help reduce operating costs by matching pump speed to the pool’s specific needs.
Built for quiet operation, the pump includes vibration dampening and a TEFC motor that resists environmental wear. The easy-to-service strainer basket and quick-release lid make routine maintenance simple. With universal plumbing compatibility and automation integration, the PLP150S is a smart, future-ready solution for efficient pool and spa operation.
Frequently asked questions
Is a variable speed pump worth it?
Variable speed pumps draw dramatically less power at low speed because energy use falls far faster than flow does. Many jurisdictions now require variable speed for new and replacement residential pool pumps above a certain horsepower, so check local code before buying single-speed.
What is the part number for this pump?
AquaStar lists this pump under part number PLP150s. Quote PLP150s when you cross-reference against your equipment manual, an existing part, or a parts diagram, so you are comparing the same revision.
How do I match a pump to my pool?
Work from the plumbing rather than the pool size: line diameter, total dynamic head and the flow your filter and heater can accept all cap the useful pump size. An oversized pump on undersized plumbing wastes power and can exceed the filter's rated flow.
How do I confirm this fits my equipment?
Match the part number stamped on the component you are replacing, or look it up in the parts list for your AquaStar equipment. If your model or serial number is not named on this page, send it to us before you order and we will confirm the fit.
What do I need to check before installing this pump?
Confirm the voltage, the union or port sizes and the mounting footprint against your existing installation. Pump replacement usually involves electrical connections and may require a licensed electrician depending on local requirements.
Is there a warranty on this pump?
It carries the standard AquaStar manufacturer warranty. The terms are set by AquaStar, and on some equipment the coverage only applies when a licensed professional performs the installation. Keep the receipt and packaging until you have confirmed correct operation.
